5W 美国UL/加拿大CUL/日本PSE标准开关电源适配器 充电器
GEO051U-0315B [3V1.5A]
GEO051U-A315B [3.3V1.5A]
GEO051U-4207B [4.2V0.7]
GEO051U-4212B [4.2V1.2A]
GEO051U-4505B [4.5V0.5A]
GEO051U-4510B [4.5V1A]
GEO051U-0505B [5V0.5A]
GEO051U-0510B [5V1A]
GEO051U-0610B [6V1A]
GEO051U-7508B [7.5V0.8A]
GEO051U-0965B [9V0.65A]
GEO051U-1205B [12V0.5A]
GEO051U-1504B [15V0.4A]
GEO051U-2425B [24V0.25A]
机械尺寸：长×宽×高＝45.5×33×23.4mm
输入电压[Input Voltage]: AC 100-240V,50/60Hz
输入电压范围[Range Voltage]: AC 90--264V,47/63Hz
输出功率[Output Power]: 5W
输出电压[Output Voltage]: 3V-24V
过压保护[Over Voltage Protection]: 120%min
过流保护[Over Current Protection]: 120%min
短路保护[Short Protection]: Auto Recovery
输出电压精度[Load Regulation]: ±5%
工作环境温度[Operating Temperature]: 0~40℃
储存温度[Storage Temperature]: -20~85℃
工作湿度[Operating Relative Humidity]: 5~95%RH
绝缘耐压[Withstanding Voltage]: AC 3000V(Min),5mA(Max)
绝缘阻抗[Insulation Resistance]: DC 500V 100MΩ(Min)
安规认证[Safety]: UL/cUL PSE CCC CE FCC BSMI CEC
主要市场[Market]:日本,美国,加拿大,中国,台湾
G051U-030120B-1 [3V@1.2A]
G051U-033120B-1 [3.3V@1.2A]
G051U-042070B-1 [4.2V@0.7]
G051U-042120B-1 [4.2V@1.2A]
G051U-045050B-1 [4.5V@0.5A]
G051U-045100B-1 [4.5V@1A]
G051U-050050B-1 [5V@0.5A]
G051U-050100B-1 [5V@1A]
G051U-060050B-1 [6V@0.5A]
G051U-060100B-1 [6V@1A]
G051U-075080B-1 [7.5V@0.8A]
G051U-090065B-1 [9V@0.65A]
G051U-120050B-1 [12V@0.5A]
G051U-150040B-1 [15V@0.4A]
G051U-240020B-1 [24V@0.25A]
